Q235B Three Side 10 Tons Mobile Dock Ramp For Container Loading
Specifications:
| Width | 2000mm~2200mm |
| Total length | 11050mm |
| Capacity | 10ton |
| Adjust range | 1200~1650mm |
| Material | Q235B(SGC490) |
| Manual pump | Import from Italy, brand is " Oiltec" |
| Ramp weight | 3200kg |
| Warranty | 1 year for hydraulic system, 3 years for steel structure |
| Color | Optional |
Application: Loading and unloading cargos
Description:
1, Our company have over 10 years experience on designing and
customize the dock ramp as per customer's request.
2, As customer request, we make this ramp with 3-side moveabble lip
design. At the busy time, can use for 3 truck or container to
loading or unloading the goods at the same time for save time.
3, Two hydraulic retractable leg help to sustain the passage of
heavy load during operation.
4, Two solid tyres provide excellent traction without worry of
puncture.
5, The end bracket enable our dock ramp to be towable by forklift.
6, The steel structure has been sand-blasted, and the painting has
been baked under 170℃ temperature, ensuring the maximum painting
adherence
and be free of rusting.
7, Capacity: 10ton or 15ton is optional.
8, Steel grating on the slope floor prevent the forklift from
slipping back during operation.
9, Top flat table is made of anti-skid steel plate.
10, We use Italy “Oiltec” hydraulic pump(optional) and it enable
our yard ramp to be operated manually
with great ease, eliminating the need for electrical operation.
11, Tapered lip edge provide a smooth transition between container
and ramp.
12, Two safety chain secure the fixing between ramp and truck box.
13, Hydraulic pump adjust the ramp to the desired position.
14, Guard rail(curb) provide safety and direction for forklift
movement.
15, Two rubber bumper absorb the shock between truck box and ramp.
16, The dimension for every part can be customized to suit to
actual demand.
17, Need to use 40' container to ship it. one 40' container can
load 2pcs.
